Type JH-EMBM Three-phase energy meter

Single-phase energy analyzer can measure imported and exported energy or be programmed to consider only the imported one. Housing for DIN-rail mounting, with IP51 front degree protection.The meter with RS485 communication.

Product Benefits

  • Single phase energy analyzer

  • Class 1 (kWh) according to EN62053-21

  • Class B (kWh) according to EN50470-3

  • Accuracy ±0.5% RDG (current/voltage)

  • Direct current measurement up to 100AAC

  • Backlit LCD display (3x 8-digit) with integrated touch key-pad

  • Energy readout on display: 6 digit

  • Variable readout on display: 2 digit

  • Energy measurement: kWh and kvarh (imported/exported); kWh+ by 2 tariffs

  • System variables, kW, kvar, V, A, PF, Hz, kWdmd, kWdmd peak

  • Dimensions: 2-DIN module

  • Pulse output (optional, by open collector PNP)

  • RS485 Modbus port (optional)

  • M-bus port (optional)
